Description
Crossover: Multiple high voltage parallel polypropylene capacitors with iron dust and air core inductors / Average impedance 6 Ohms.
Crossover frequencies:
- Bass to Mid 300Hz
- Mid to High Frequency 6kHz
- ZRR-10 tweeter unit sensitivity 88dB
- 8 layer 125mm bass drive unit – 75Hz
- 8 layer 200mm bass drive unit – 40Hz /Bi-wireable
- Bi-ampable – Yes
Cabinet construction and finish:
- Available in High gloss Cherry, Piano Black or Walnut
- 25mm thick high density cabinet, 1/4 wave transmission line design
Cabinet dimensions:
- H 1005mm x D 440mm x W 200mm
- 300mm foot print.
Weight per speaker: 38Kg.
Power handling figures are quoted as a guide.
Amplification between 30w and 500w can be used safely depending on the quality of amplification.
