Description
- 105 Watts per channel into 8
- 127 Watts per channel into 6
- 162 Watts per channel into 4
- Input sensitivity for 105 Watts into 8
- Line inputs (input 1 switch set to line) 1-5 and record – 196mV load 10K
- Phono (input 1 switch set to phono) – 2mV Load 47K in parallel with 220pF
- Direct input – 760mV Load 50K
- Power amplifier gain – 31.6dB
- Record output – 196mV for rated inputs
- Pre-amplifier output – 760mV for rated inputs
- Dimensions: W 432mm x D 325mm x H 82mm
- Weight – 13kg
